How many inverters can be connected to a MV station?
The Inverter Manager and the I/O Box can be installed in the MV Station as an option and can control the output of the inverters. Up to 42 inverters can be connected to one Inverter Manager. This means that PV systems can be designed with several MV stations, whereby not every MV station has to be fitted with an Inverter Manager.
How many Sunny Tripower inverters can be connected to the MV station?
Up to 30 Sunny Tripower inverters can be connected to the MV Station. Several MV Stations can be connected together to form a ring or string on the medium-voltage side. The Inverter Manager and the I/O Box can be installed in the MV Station as an option and can control the output of the inverters.
How many inverters can be connected to one inverter manager?
Up to 42 inverters can be connected to one Inverter Manager. This means that PV systems can be designed with several MV stations, whereby not every MV station has to be fitted with an Inverter Manager. The AC low-voltage cables from the inverters are connected in the low-voltage compartment.
How high should the MV station be installed?
In areas subject to strong precipitation or high groundwater levels, a drainage system must be implemented. To avoid the ingress of water as a result of rain, the MV Station is not to be installed in a depression. To facilitate accessibility for servicing operations, the MV station is to be mounted at a height of no more than 0.5 m.
What temperature is the MV station suitable for?
The standard version of the MV Station is suitable for mounting locations with ambient temperatures of up to +40°C. Ambient temperatures of up to +50°C are possible if the appropriate order option is selected. The ambient conditions must comply with classification 4S2.
Can MV station configurations be combined?
You can use the option code to select an MV Station configuration which is tailored specifically to your project. However, not all order options can be combined with each other. Consult your SMA contact person if you have any questions. Check the scope of delivery for completeness and any externally visible damage.
