How do I install a booster power supply (BPS)?
Follow these steps to install and set up the booster power supply (BPS). Verify that all power and field wiring are de-energized before proceeding. Unpack the equipment. Review the “Getting started” section. Review the applications: Review the applications to determine how you want to use the BPS. See the “Applications” section.
What is a booster power supply?
The 10 Amp and 6.5 Amp Booster Power Supplies (BPS) are designed to extend a fire alarm panel’s signaling capacity. The Booster can be connected to existing Class A or Class B Notification Appliance Circuits (NACs) or activated via Signature Series modules. There are four independent 3.0 Amp NAC circuits supervised in a non-alarm condition.
Can a booster power supply be connected to a 24VDC system?
The input circuits of the booster power supply can be connected to 12 VDC or 24 VDC systems. For details about device compatibility, refer to the Remote Booster Power Supply Compatibility List (P/N 3100656). Follow these steps to install and set up the booster power supply (BPS).
What is a booster power supply trouble relay?
10 Booster Power Supply Manual Trouble relay wiring The Booster Power Supply has a Form C trouble relay that provides a normally open and normally closed contact. The trouble relay will deactivate under any trouble condition. A 16-second delay is used on the trouble relay for AC fail and brownout troubles.
What are 6.5 a and 10 a booster power supplies?
The 6.5 A and 10 A booster power supplies are designed to extend the power capacity of an emergency communication, life safety, fire alarm, security, or access control system. You can activate the BPS from options modules or from a control circuit. It has four independent NAC/AUX circuits that are supervised, when configured for NAC.
How many booster modules are allowed per NAC?
A maximum of 10 modules are allowed per NAC. The maximum total for parallel EOL’s is 4.7 K. 14 Booster Power Supply Manual Out to EOL or next device UL Listed EOL 15 K EOL 15 K NAC Circuit From existing fire alarm panel notification circuit or CC1 module
